Product Overview
High-performance cylindrical UV digital flatbed printer designed for cups, bottles, and cylindrical objects with exceptional speed and precision.
Key Features
-
High Precision: 3.5pl droplet size provides optimal balance between throughput and print quality for various applications.
-
High Resolution: Multiple inkjet schemes adapt to different printing materials with accurate colors, distinct layers, and smooth transitions.
-
Intelligent Maintenance: Automatic nozzle flashing and moisture retention during non-working states prevents blockage from ink curing.
Technical Specifications
| Model |
CF-2510 (Duplex) |
| Nozzle Type |
Ricoh GEN 5i |
| Print Size |
235cm × 63.2cm |
| Printing Height |
0-15cm (Customizable) |
| Equipment Size |
412cm × 159cm × 144cm |
| Equipment Weight |
860kg |
| Printing Software |
Photoprint / PrintFactory |
| Ink Type |
LED Environmental Protection UV Ink |
| Ink Colors |
W + CMYK + Varnish |
| Maximum Power |
3000W |
| Effective Orifice |
1280 |
| Ink Drop Volume |
3.5PL |
| Nozzle Length |
27MM |
| Single Nozzle Color |
4 |
| Rated Voltage |
240V 50/60HZ |
Manufacturer Profile
Guangzhou Skydeekenutek Co., Ltd. specializes in distribution and wholesale of UV printers, including single-pass UV printers, UV flatbed printers, UV mesh belt printers, banner printers, and crystal label printers. Our 2500 m² factory in Panyu, Guangzhou employs over 10 R&D staff and 150 workers with ISO certification, strict quality control, and comprehensive production management. We support OEM and ODM services with over 10 years of UV printer manufacturing experience, exporting to France, Germany, Vietnam, India, and other countries. All products carry CE and RoHS certifications.
Packaging & Shipping
Certifications
Frequently Asked Questions
Q1: Do I need white ink and varnish ink?
White ink enables high-quality graphics on various materials, including non-white substrates, while varnish enhances brightness and extends UV ink fade resistance.
Q2: What materials can UV flatbed printers print on?
All flatbed media including PP/PVC boards, KT boards, acrylic, plexiglass, metal, tiles, phone cases, wood boards, rigid identification boards, hard cardboard, corrugated boxes, glass, tiles, wood, and furniture. UV printing eliminates coating, fading, and blistering issues while saving significant working hours.
Q3: Which languages does the RIP installation interface support?
Korean, German, French, Finnish, Dutch, Portuguese, Japanese, Spanish, Italian, English, Simplified Chinese, and Traditional Chinese.
Q4: How is the after-sales service?
Our experienced technicians provide comprehensive technical support, including operational training until full mastery. Our technical team may also conduct international testing and repair services.
Q5: Regarding printer maintenance
We recommend daily ink pressing when the printer is turned on. For periods exceeding 10 days of non-use, clean the print head with cleaning fluid and maintain nozzle moisture.
Q6: Are you a factory or a foreign trade company?
We are a factory, enabling us to offer competitive pricing and high-quality services.
